Automatic Rapid Vertical Lifting Industrial Sectional Doors
Polyurethane Foam Insulation
Main features:
| Using location | External Door |
| Door curtain material | Steel sandwich construction |
| Door Panel Sections: | Pinch-resistant;500mm height for each piece panel; |
| Door panel thickness | 40, 50, 80 mm Polyurethane foam |
| Track section | 2mm Aluminum Alloy steel; C-profile anti-wind track |
| Lifting system | Normal Lift, High lift, Vertical Lift |
| Door designing | Counterbalance System:Precision-engineered by professional program; Torsion spring material is 60Si2Mn. Torsion spring with special heat treatment & oil immersion
anti-rust treatment,providing a minimum 20000 cycles. Optional in galvanizing process surface spring to meet more and
longer using. |
| Door operation | Sectional door Unique motor |
| Window or Pedestrian Door | Supporting |
| Heating function | Heat conduction factor: 0.38W/mc |
| Acoustic insulation | Acoustic insulation: 24dB (DIN52210) |
| Mechanical Part | Torsion mechanism including shaft, spring plugs and cable drums |
| Opening& Cloding speed | 0.2-0.5m/s |
| U value | 0.38w/mc |
Our professional system in the whole service processing
We have the best solution for you, and we provide all the support
you need to achieve optimum results, or value, or both, from
whatever products you buy. We promise you must have an
unforgettable experience between our business.
Industrial and sectional door's charactor
The industrial door, as the best choice of the outdoor of the
modern architecture, enjoys the perfect durability and sealing, the
high speed, the elegant aprrearance, the simple operating system
and the spring balanced system, which is used durably and cleaned
easily with the special designing door panel.
The Features of Sectional Doors:
Segmented Structure: The door is made up of multiple horizontal panels connected by
hinges, allowing it to bend and move smoothly along a track.
Vertical Opening, Space Saving: The door opens vertically and rests parallel to the ceiling,
maximizing both interior and exterior space.
Excellent Sealing: Equipped with sealing strips around the edges, sectional doors
offer good insulation, dustproofing, and weather resistance.
High Strength and Safety: Typically made of steel panels with polyurethane cores, they are
strong yet lightweight and often come with anti-fall protection
systems for enhanced safety.
Versatile Appearance: Available in various colors, finishes, and designs, making them
suitable for industrial, commercial, and residential applications.
Manual or Automatic Operation: Can be operated manually or powered by an electric motor,
offering flexible usage options.
Easy Maintenance: Damaged sections can be replaced individually without needing to
replace the entire door.
Our specialty
- We can provide the scheme for you according to the customer.
- We can provide the installation drawing for you.
- We can provide the right door-choosing suggestion.
- We can provide the installation guidance.
- We can provide the professional service supporting.
- We can provide the operating guidance and instruction.
- We accept your acquirment and consulting suggestion.
