Industrial Stronger Anti-wind Pipe High Speed Doors Rolling
Shutters
The charactor of Automatic and High Performance Speed Door:
Automatic and High Performance Speed Door is the solution to the
high-level clean environment
which needs prevent dust and clean easily in the busy passageway
area with high clearness demands,
strong wind-resistance,especially for food,pharmacy,fine machining
industry and so on.
1) Smooth operation during the whole processing.
2) More durable use by the unique and professional curtain
material.
3) More beautiful/elegent appearance.
4) Anti-bacteria protection system.
5) Our owned Trade - Mark and professional developing & researching
team.
6) Sustained innovation on the product.
Main feature:
Curtain Color | Blue, Orange,Yellow, Red, Grey, White,Green. |
Viewing Window | Full transparent 1.5mm PVC window. |
Power supply | AC 220V - 240V,Single- 3 Phrase, 50HZ |
Anti-bar width | 60mm or stronger anti-wind pipe |
Temperature | -7 to 65 Celsius degree |
Normal Working | -5 to 65 Celsius degree |
Standard Motor Position | Left |
Installation Base | Concrete,Panel, Brick,Steel Structure. |
Installation Space | ≥600mm above the door
≥600mm for motor side
≥200mm for non-motor side
≥800mm in front of the door |
Using Area | For Production Line |
Specifications:
Technical Parameter for speed door
Max Size:5000mm(W)*5000mm(H)
Opening Speed:1.0m/s
Closing Speed:0.6m/s
Wind load Max:28m/s
Mechanical Unit
Frame:304 Stainless Steel
Inner Frame:Anti-wear Nylon Molded Inner frame
Thickness of frame:2.0mm Stainless Steel
Thickness of shaft cover:1.5mm 304 Stainless Steel
Motor cover:Yes
Frame Size:120mm*120mm
Control Unit
Control system:
- S150 FU Micro-processor
- English Man-Machine Interface
- Self Trouble-Shooting Recognizing system
- Bigger LED Screen
Control Box Size:320 X 400 X 210 mm
Driving System
Feature:Absolutely Encoder
Driving Unit Brand:ABB Motor / Yaskawa Frequent Convert
Activation System
Open and Close the door:
- Radar
- Induction Loop
- Remote
- Card Sensor
- Pull Cord
- Push Button
- Touching Panel for Cleaning Room
- Central-Computer Controlling
Safety System
Safe Equipment:
- Beep
- Anti-wind Bar
- Traffic Light
- Wireless safety Edge
- Built-in Photo Cell
- Emergency Handle
- Shoulder Protection
Our specialty
- We can provide the scheme for you according to the customer.
- We can provide the installation drawing for you.
- We can provide the right door-choosing suggestion.
- We can provide the installation guidance.
- We can provide the professional service supporting.
- We can provide the operating guidance and instruction.
- We accept your acquirment and consulting suggestion.
